Design standard for the foundation of towers and columns. Use this standard for study purposes only.
A typical title block on a design drawing will include the following information:
|
General Notes
|
||||
| For general notes see dwg. ... |
||||
|
Materials
|
||||
|
Material
|
Quality
|
|||
| Concrete Plan bars Deformed bars Wire mesh |
||||
| Cement content (kg/m3) Type and class of cement Concrete cover to, outer most bar (mm) |
||||
|
Net Quantities
|
||||
| Item | Blinding conc. |
Conc. | Wire Mesh |
Other |
| m3 | m3 | m2 | - | |
|
Reference Drawings
|
||||
| Fnd. Location Plan ... Bending Schedule ... |
||||
The next figures show a typical design for the foundation of a tower:
